304 INOX 1.4301 Stainless Steel Tubing , Ss Pipe Welding Long Life Time

JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap 304 INOX 1.4301 Stainless Steel Tubing , Ss Pipe Welding Long Life Time from wholesalers

    Buy cheap 304 INOX 1.4301 Stainless Steel Tubing , Ss Pipe Welding Long Life Time from wholesalers
    • Buy cheap 304 INOX 1.4301 Stainless Steel Tubing , Ss Pipe Welding Long Life Time from wholesalers
    • Buy cheap 304 INOX 1.4301 Stainless Steel Tubing , Ss Pipe Welding Long Life Time from wholesalers
    • Buy cheap 304 INOX 1.4301 Stainless Steel Tubing , Ss Pipe Welding Long Life Time from wholesalers

    304 INOX 1.4301 Stainless Steel Tubing , Ss Pipe Welding Long Life Time

    Ask Lasest Price
    Brand Name : MITTEL
    Model Number : 304
    Certification : SGS ISO MTC
    Price : 2.65 USD/KG
    Payment Terms : L/C, T/T
    Supply Ability : 50000KGS
    Delivery Time : 14 Days
    • Product Details
    • Company Profile

    304 INOX 1.4301 Stainless Steel Tubing , Ss Pipe Welding Long Life Time


    304 Stainless Steel Welded Pipe INOX 1.4301 Stainless Steel Tubing

    Detailed Product Description

    Test:Squash Test, Extended Test, Water Pressure Test, Crystal Rot Test, Heat Treatment, NDTApplication:Handrail,weldmesh Screen,door,window, Balcony,fence,furniture,etc
    Material Grade:304,316,201,202, 316L,430Outer Diameter:6mm-101.6mm
    Standard:ASTM A554, A312, A249, A269 And A270,A688Surface:Polished
    Type:Stainless Steel Welded Tube / PipeWall Thickness:0.6mm-3mm

    304 316 201 202 Stainless Steel Welded Tube for Furniture ASTM A554 A312 A249


    Quick Detail:

    Welded Stainless Steel tube As per ASTM A249/A269,polished, for fluid and decorative
    1 Standard: ASTM A249/269
    2 Material:304,316,201,202, 316L,430
    3 OD: 6mm-101.6mm
    Wall: 0.6mm-3mm
    4 Surface:polished

    NameStainless steel welded tube
    StandardASTM A554, A312, A249, A269 and A270,A688
    Material Grade304,316,201,202, 316L,430
    Size Range20x10mm--100x50mm,10x10mm-100x100mm, 9.53-101.6mm, we can also accept sizes above 101.6mm
    Thickness0.3mm - 3.0mm
    Length6m or as customers' request

    Tolerance
    a) Outer Diameter: +/- 0.2mm
    b) Thickness: +/- 0.02mm
    c) Length: +/- 5mm
    Surface180G, 320G Satin / Hairline(Matt Finish, Brush, Dull Finish)
    400G, 600G Mirror finish
    ApplicationHandrail,weldmesh screen,door,window, balcony,fence,furniture,etc
    TestSquash test, Extended test, Water pressure test, Crystal rot test, Heat treatment, NDT




    Chemical Composition of Material

    Composition

    Material
    201202304316L430
    C≤0.15≤0.15≤0.08≤0.35≤0.12
    Si≤1.00≤1.00≤1.00≤1.00≤1.00
    Mn5.5-7.57.5-10≤2.00≤2.00≤1.00
    P≤0.06≤0.06≤0.045≤0.045≤0.040
    S≤0.03≤0.03≤0.030≤0.030≤0.030
    Cr13-1514-1718-2016-1816-18
    Ni0.7-1.13.5-4.58-10.510-14
    Mo2.0-3.0

    Mechanical Property
    Material Item201202304316
    Tensile Strength≥535≥520≥520≥520
    Yield Strength≥245≥205≥205≥205
    Extension≥30%≥30%≥35%≥35%
    Hardness (HV)<105<100<90<90



    The welded stainless steel pipe is made from stainless steel by electric welding or sheet metal strips by means of forming and welding. Electrically welded tube is made of thermally without subsequent processing and hot-reducing.


    Our Advantages:

    1, Direct material sourcing from Bao Steel, ZPSS, TISCO.
    2, More than 5 processing mills to produce the welded titanium tube for us. And also we own a steel tube mill.
    3, Strong business cooperation with Bao Steel and Shanghai Minmetals.
    4, More than usd$50,000,000 annual turnover.

    304 INOX 1.4301 Stainless Steel Tubing , Ss Pipe Welding Long Life Time304 INOX 1.4301 Stainless Steel Tubing , Ss Pipe Welding Long Life Time304 INOX 1.4301 Stainless Steel Tubing , Ss Pipe Welding Long Life Time
