Type 441 2D Polished Stainless Steel Sheet Metal 1.4509 X2CrTiNb18 Material Properties 3.012602440mm

Ask Lasest Price
Brand Name :	TISCO BAO STEEL QPSS
Model Number :	441
Certification :	SGS ISO MTC BV
Price :	2.35 USD/KG
Payment Terms :	L/C, T/T
Supply Ability :	50000KGS
Delivery Time :	14 DAYS

Add to Cart

Product Details
Company Profile

Type 441 2D Polished Stainless Steel Sheet Metal 1.4509 X2CrTiNb18 Material Properties 3.012602440mm

Type 441 stainless steel 441 stainless sheet 1.4509 material properties

Product Name	High quality cheap aisi 441 stainless steel sheet 0.4-10mm thick
Width	1000mm,1219mm,1500mm,1800mm,2000mm,2500mm,3000mm, 3500mm,etc
Length	2000mm,2440mm,3000mm,5800mm,6000mm,etc
Thckness	0.1-200mm
Standard	ASTM A240,GB/T3280-2007,JIS4304-2005,ASTM A167,EN10088-2-2005,etc
Technique	hot rolled, cold rolled
Surface Treatment	2B,2D,BA,NO.1,NO.4,NO.8,8K,mirror ,brush,checkered ,embossed,hair line,sand blast,etching,etc
Thickness tolerance	+/-0.1mm-0.5mm
Material	441
Application	Stainless steel plate applies to construction field, ships building industry, petroleum,chemical industries,war and electricity industries, food processing and medical industry, boiler heat exchanger, machinery and hardware fields. Stainless steel plate can be made Accordingto the customers requirements.
Terms of payment	T/T , LC at sight, Westen union.
Shipment time	7-15 days after receive the deposit.
Term of price	EXW,FOB, CNF, CIF, FCA,DDU,DDP.
Export packing	Standard export package,suit for all kinds of transport,or as required

Grade :

X2CrTiNb18 441

Number:

1.4509

Classification:

Ferritic stainless steel - special grade

Density:

7.75 g/cm ³

Standard:

EN 10088-2: 2005 Stainless steels. Technical delivery conditions for sheet/plate and strip of corrosion resisting steels for general purposes

EN 10088-3: 2005 Stainless steels. Technical delivery conditions for semi-finished products, bars, rods, wire, sections and bright products of corrosion resisting steels for general purposes

EN 10028-7: 2007 Flat products made of steels for pressure purposes. Stainless steels

EN 10296-2: 2005 Welded circular steel tubes for mechanical and general engineering purposes. Stainless steel. Technical delivery conditions

EN 10088-1: 2005 Stainless steels. List of stainless steels

EN 10088-4: 2009 Stainless steels. Technical delivery conditions for sheet/plate and strip of corrosion resisting steels for construction purposes

Chemical composition % of steel X2CrTiNb18 (1.4509): EN 10088-2-2005

Nb = ( 3 * C + 0.3 ) to 1.0
Elements not listed in this table shall not be intentionally added to the steel without the agreement of the purchaser except for finishing the cast.

C	Si	Mn	P	S	Cr	Nb	Ti
max 0.03	max 1	max 1	max 0.04	max 0.015	17.5 - 18.5	0.3 - 1	0.1 - 0.6

Mechanical properties of steel X2CrTiNb18 (1.4509)


Rm - Tensile strength (MPa) (+A)	430-630


Rp0.2 0.2% proof strength (MPa) (+A)	200-250


A - Min. elongation at fracture (%) (+A)	18

Brinell hardness (HB): (+A)

200

Properties of steel X2CrTiNb18 (1.4509)

Resistance to intergranular corrosion: in the delivery condition - yes; in the welded condition - yes

Equivalent grades of steel X2CrTiNb18 (1.4509)

Ferritic AISI 441, EN 1.4509, DIN X2CrTiNb18 stainless steel sheet and coil

Type 441 is an 18% chromium, dual stabilized ferritic stainless steel with corrosion resistance

similar to that of 304/304L stainless steel. This grade may be used in the annealed, cold formed

or as-welded condition in applications where other stainless steels such as Type 304/304L and

Type 430 are used. Type 441 has good weldability due to titanium and niobium stabilization and

has excellent resistance to stress corrosion cracking. Type 441 outperforms Type 409 in both oxidation

and corrosion resistance and typical applications include automotive manifolds and exhaust system components.

The high temperature strength of Type 441 exceeds that of both Types 439 and 409 stainless steels.

Standards
AISI 441, UNS S43932, JIS SUS441, EN 1.4509, DIN X2CrTiNb18

Chemical composition of stainless 441

Grade	C	Si	Mn	P	S	Cr	Ni	Nb	N	Ti
441	0.03	1.00	1.00	0.040	0.030	17.5~19.5	1.00	0.3+9XC min, 0.90 max	0.030	0.10~0.50

Mechanical properities

Tensile strength	Yield strength	Elongation	Hardness
490	310	32	B78

We stock 441, 1.4509 hot and cold rolled stainless steel sheet, plate, strip and coil.

please welcome to contact us.

EU
EN

USA
-

France
AFNOR

X2CrTiNb18

S43932

S43940

Z3CTNb18

Type 441 2D Polished Stainless Steel Sheet Metal 1.4509 X2CrTiNb18 Material Properties 3.0*1260*2440mm
