Hastelloy C276 Pipe Seamless Pipe N10276 1" DN25 2.77mm Thickness Hastelloy C276 Pipe Fittings

Product Categories
JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Hastelloy C276 Pipe Seamless Pipe N10276 1" DN25 2.77mm Thickness Hastelloy C276 Pipe Fittings from wholesalers

    Buy cheap Hastelloy C276 Pipe Seamless Pipe N10276 1" DN25 2.77mm Thickness Hastelloy C276 Pipe Fittings from wholesalers
    • Buy cheap Hastelloy C276 Pipe Seamless Pipe N10276 1" DN25 2.77mm Thickness Hastelloy C276 Pipe Fittings from wholesalers
    • Buy cheap Hastelloy C276 Pipe Seamless Pipe N10276 1" DN25 2.77mm Thickness Hastelloy C276 Pipe Fittings from wholesalers

    Hastelloy C276 Pipe Seamless Pipe N10276 1" DN25 2.77mm Thickness Hastelloy C276 Pipe Fittings

    Ask Lasest Price
    Brand Name : MITTEL
    Model Number : C276
    Certification : SGS ISO MTC
    Price : 28.5 USD/KG
    Payment Terms : L/C, T/T
    Supply Ability : 50000KGS
    Delivery Time : 7 Days
    • Product Details
    • Company Profile

    Hastelloy C276 Pipe Seamless Pipe N10276 1" DN25 2.77mm Thickness Hastelloy C276 Pipe Fittings

    Hastelloy C276 Pipe Seamless Pipe N10276 1" DN25 2.77mm Thickness Hastelloy C276 Pipe Fittings

    What Is Hastelloy C276 Pipe Vs Tube
    Hastelloy C276 pipes and tubes are used interchangeably in the piping industry. These common grades can be distinguished based on certain features.

    • Hastelloy C276 pipe is always designed with a circular cross-section. Tubes can be manufactured in a square, rectangle, and circular shapes.
    • A Hastelloy grade C276 pipe can be measured based on the nominal size and schedule number. Tubes in the C276 Hastelloy grade are manufactured and identified with their wall thickness and outer diameter.
    • Hastelloy C276 tubes are stronger in comparison to alloy C276 pipes
    • Alloy C276 Pipes are designed to accommodate larger applications, while alloy C275 tubes are designed to work well with smaller diameter applications.

    Hastelloy C276 Seamless Pipe Vs Welded Pipe
    Hastelloy C276 grade modules are designed in seamless and welded configurations. Both these manufacturing grades can be distinguished based on certain features.

    • Hastelloy C276 seamless pipe is manufactured by passing hot steel billets through extruded metal components. Alloy C276 welded pipes are produced by welding sheets or strips in place to precisely form the module.
    • Alloy C276 pipes have superior strength and enhanced load-bearing capacity when compared to a welded pipe grade.
    • A welded pipe of this grade shows the presence of seams or welds, while seamless pipe doesn’t possess any welds or seams.
    • Hastelloy C276 welded pipes are cheaper than standard seamless pipes in this grade.

    What Kind of Metal Is Hastelloy B622 N10276 Pipe
    Hastelloy B622 N10276 pipe is a titanium stabilized pipe that has a superior concentration of chromium, nickel, and molybdenum. The material in this grade showcases enhanced corrosion and oxidation resistance across reducing environments. The modules work in temperatures up to 1900 degrees F and can be easily hardened by heat treatment methods.

    Manufacturer and exporter of WERKSTOFF NR. 2.4819 ERW Pipe in China, Have difficulty to find Hastelloy C276 Alloy EFW Pipe, UNS N10276 Round Pipes and ASME SB622 Nickel Alloy C276 Welded Pipe in tough sizes

    Looking to buy Schedule 40 Hastelloy C-276 Square Tube inchina Supply Cut to length WNR/ DIN 2.4819 Welded Pipe, ASTM B619 Alloy C276 Round Pipes and Hastelloy C276 Seamless Pipe Manufacturer i

    Hastelloy C276 Pipe Specification

    TypesWall thicknessOut diameterLength
    Hastelloy C276 Seamless Pipe (Custom Sizes)As per requirement5.0mm ~ 203.2mmUpto 6 Meters
    NB Sizes (in stock)SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 1601/8” ~ 8”Upto 6 Meters
    Hastelloy C276 Welded Pipe (in Stock + Custom Sizes)1.0 ~ 15.0 mm5.0mm ~ 1219.2mmUpto 6 Meters

    UNS N10276 Pipe Chemical Composition

    Alloy C276FeNiPCSMoCoMnCrSi
    4.00 – 7.00Balance0.04 max0.010 max0.03 max15.00 – 17.002.5 max1.00 max14.50 – 16.500.08 max

    Alloy C276 Pipe Mechanical Properties

    DensityYield Strength (0.2%Offset)Melting PointElongationTensile Strength
    8.89 g/cm3Psi – 52,000 , MPa – 3551370 °C (2500 °F)40 %Psi – 1,15,000 , MPa – 790

    Alloy C276 Seamless Pipe Equivalent

    We Guarantee Fastest Delivery of 2.4819 Hastelloy C-276 Round and Rectangular Pipe in various wall thicknesses for high temp applications in India. Check dimensions of Alloy C276 Welded Pipes, 2.4819 Rectangular Pipe and Hastelloy C276 Tube with All Documents Including MTC and EN 10204/3.1B Mill Test Certificate
    STANDARDENUNSJISWERKSTOFF NR.GOSTAFNORBS
    Hastelloy C276NiMo16Cr15WN10276NW 02762.4819ХН65МВУ––

    Hastelloy WERKSTOFF NR. 2.4819 Pipe Gauge Thickness

    GAUGETYPICAL VALUE (INCH)THICKNESS RANGE (INCH)
    220.0280.025 - 0.029
    200.0350.031 - 0.035
    190.0420.038 - 0.042
    180.0490.044 - 0.049
    170.0580.053 - 0.058
    160.0650.060 - 0.065
    150.0720.066 - 0.074
    140.0830.075 - 0.085
    130.0950.087 - 0.097
    120.1090.101 - 0.111
    110.120.112 - 0.122
    100.1340.126 - 0.136
    90.1480.140 - 0.150
    80.1650.157 - 0.167
    70.180.175 - 0.185

    Alloy C276 Pipe Physical Properties

    Density8.9gcm3
    Melting point1325-1370oC

    Hastelloy C276 Seamless Tube Tolerances

    O.D. INCHESO.D. +/- INCHESWALL THICKNESS INCHES
    1 to 1-1/2" incl..008.025 to .065
    .010Over .065 to .134
    1/2" to 1" incl..005.025 to .065
    .010Over .065 to .134
    1-1/2" to 2" incl..010.025 to .049
    .011Over .049 to .083
    .012Over .083 to .148
    2-1/2" to 3-1/2" incl..014.032 to .165
    .020Over .165 to .220
    2" to 2-1/2" incl..012.032 to .065
    .013Over .065 to .109
    .014Over .109 to .165
    3-1/2" to 5" incl..020.083 to .165
    .025Over .165 to .220

    Hastelloy C276 Pipe Sizes

    Wall ThicknessHastelloy C276 Tube Sizes & Pipe Size ( O.D.)
    .0351/8" , 3/16" , 1/4" , 5/16" , 3/8" , 7/16" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 2" , 2 1/4"
    .0101/16" , 1/8" , 3/16"
    .0493/16" , 1/4" , 5/16" , 3/8" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/8" , 1 1/4" , 1 1/2" , 1 5/8" , 2" , 2 1/4"
    .0201/16" , 1/8" , 3/16" , 1/4" , 5/16" , 3/8"
    .0651/4" , 5/16" , 3/8" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 1 3/4" , 2" , 2 1/2" , 3"
    .0121/8"
    .0831/4" , 3/8" , 1/2" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 1 7/8" , 2" , 2 1/2" ,3"
    .0161/8" , 3/16"
    .0951/2" , 5/8" , 1" , 1 1/4" , 1 1/2" , 2"
    .0281/8" , 3/16" , 1/4" , 5/16" , 3/8" , 1/2" , 3/4" , 1" , 1 1/2" , 2"
    .1341"
    .1091/2" , 3/4" , 1" , 1 1/4" , 1 1/2" , 2"
    .2503"
    .1201/2" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 2" , 2 1/4" , 2 1/2" , 3"
    .3753 1/2"
    .1253/4" , 1" , 1 1/4" , 1 1/2" , 2" , 3" , 3 1/4"

    Hastelloy Tube Hardness

    Tubing MaterialRecommended Temperature RangeGeneral Application
    hastelloy Tubing-205°F to 1200°F (-130°C to 650°C)Recommended for High Temperature Applications with Generally Corrosive Media -
    MaterialConditionTypeMax. Recommended HardnessASTM Tubing Specifications
    hastelloy TubingFully AnnealedC276/C2290 RbASTM B622

    Hastelloy Alloy C276 Round Pipe Various Supplies

    • alloy 75
    • AMS 5886
    • msrr material specs
    • msrr 7115
    • c1023 material
    • msrr 6522

    Hastelloy C276 Pipe Seamless Pipe N10276 1" DN25 2.77mm Thickness Hastelloy C276 Pipe Fittings
