    SUS 409L ERW Stainless Steel Welded Pipe Annealed Size 31.8 * T1.0* 5800

    Ask Lasest Price
    Brand Name : MITTEL TISCO BAO STEEL
    Model Number : 409L
    Certification : SGS ISO MTC
    Price : 2.15 USD/KG
    Payment Terms : L/C, T/T
    Supply Ability : 50000KGS
    Delivery Time : 7 Days
    • Product Details
    • Company Profile

    SUS 409L ERW Stainless Steel Welded Pipe Annealed Size 31.8 * T1.0* 5800

    SUS 409L Size 31.8 * T1.0* 5800 size 54 * T1.2* 5800 Stainless Steel Welded Pipe

    Product Details of 409L STAINLESS STEEL PIPE


    Grade409L STAINLESS STEEL PIPE
    StandardJIS/SUS/GB/DIN/ASTM/AISI/EN
    TechniqueWelded
    Wall Thickness0.5-3mm
    Out Diameter6mm-325mm
    Length3000mm, 4000mm,5800mm,6000mm,12000mm,or as required.
    Surface treatmentPolishing,annealing,pickling,bright
    ApplicationWidely used in petroleum,foodstuff,chemical industry,construction, electric power,nuclear,energy,machinery,biotechnology,paper making,shipbuilding,boiler fields.
    Lead Time7-15 working days after the receipt of 30% deposit
    Payment Terms30% TT for deposit,70% TT /70% LC at sight balance before shipment
    Price TermsFOB, EXW, CIF, CFR
    PackingStandard Seaworthy Package or according to customer's requirements

    Chemical Composition of ASTM A268 409 S40900 Grade and EN 10088-2 1.4512 1.4516 Stainless Steel

    GradeCMnSiPSCrNiTi
    A268 409min. max.– 0.08– 1.00– 1.00– 0.045– 0.03010.5 11.7– 0.506×C-0.75
    TP409Lmin. max.– 0.035– 1.00– 1.00– 0.045– 0.03010.5 11.7– 0.506×C-0.75
    1.4516min. max.– 0.08– 1.50– 0.70– 0.040– 0.01510.5 12.50.50-1.500.05-0.35
    1.4512min. max.– 0.030– 1.00– 1.00– 0.040– 0.01510.5 12.5– 0.506×(C+N)-0.65

    Mechanical properties of ASTM A268 409 Grade and EN 10088-2 1.4512 stainless steel

    GradeTensile StrengthYield Strength 0.2% ProofElongationHardnessHardness
    Gradeksi(MPa) minksi (MPa) min(% in 50mm) minRockwell B (HR B) maxBrinell (HB) max
    40955 (380)25 (170)2095207
    1.4512380-56021025

    Typical physical properties for annealed grade 409 stainless steels are given in table 3.

    Table 3. Physical properties of 409 grade stainless steel in the annealed condition

    GradeDensity (kg/m³)Elastic Modulus (GPa)Mean Coefficient of
    Thermal Expansion
    (mm/m/°C)
    Mean Coefficient of
    Thermal Expansion
    (mm/m/°C)
    Mean Coefficient of
    Thermal Expansion
    (mm/m/°C)
    Thermal Conductivity
    (W/m.K)
    Thermal Conductivity
    (W/m.K)
    Specific Heat 0-100°C (J/kg.K)Electrical Resistivity (nW.m)
    0-100°C0-315°C0-538°Cat 100°Cat 500°C
    409760020811.011.712.425.827.5460600

    SUS 409L ERW Stainless Steel Welded Pipe Annealed Size 31.8 * T1.0* 5800SUS 409L ERW Stainless Steel Welded Pipe Annealed Size 31.8 * T1.0* 5800SUS 409L ERW Stainless Steel Welded Pipe Annealed Size 31.8 * T1.0* 5800
